製品情報

ESC4000 DHD G4

製品種別 サーバ
CPU

筐体サイズ 2U
電源仕様 リダンダント電源
用途/特長
製品説明

製品仕様

Processor / System Bus 2 x Socket P (LGA 3647)
1st and 2nd Gen Xeon® Scalable Processor Family
*Refer to support page for more information
Core Logic Intel® C621 Chipset
Memory Total Slots : 16 (6-channel per CPU, 8 DIMM per CPU)
Capacity : Maximum up to 2048GB RDIMM
Memory Type :
DDR4 2933/2666 RDIMM
DDR4 2933/2666 LRDIMM
2933/2666 LR-DIMM 3DS
Intel® Optane™ DC Persistent Memory
Memory Size :
64GB, 32GB RDIMM
128GB, 64GB, 32GB LRDIMM
128GB, 64GB LR-DIMM 3DS
* Refer to support page for more information
Expansion Slots Total: 4 + 2
Full-length/Full-height
4 * PCI-E 3.0 x16 (4 x16 Link)from CPU1

Half-length/Low-profile
2 * PCI-E 3.0 x16 (support with riser card),1 from CPU1, 1 form CPU2
Storage SATA Controller :
Intel® C621
4 x U.2 connector (supports U.2 NVMe device)
4 x M.2 connector(2242/2260/2280/22110) PCIe mode
Intel® Rapid Storage Technology Enterprise(RSTe) (For Linux/Windows)
(Support Software RAID 0, 1, 5, 10 )
Intel®VROC (For Linux/Windows)
(Support Software RAID 0/1/5/10 )
SATA Controller :
Intel® C621
4 x SATA3 6Gb/s ports (Optional)
Drive Bays 4 x 2.5" hotswap NVMe/SATA bay (front)
Networking 1 x Dual Port Intel X550-AT2 10GbE LAN controller + 1 x Mgmt LAN
Graphic Aspeed AST2500 with 64MB VRAM
Front I/O Ports 2 x USB 3.2 Gen1
Rear I/O Ports 2 x USB 3.2 Gen1 ports
1 x VGA port
1 x RJ-45 Mgmt LAN port
2 x RJ45 10G LAN ports
Switch/LED Front Switch/LED:
1 x Power switch/LED
1 x Reset switch
1 x Location LED
1 x SSD Access LED
1 x Message LED
4 x M.2 Access LED
OS Support Please find the latest OS support from https://www.asus.com/event/Server/OS_support_list/OS.html
Management Solution ACC
On-Board ASMB9-iKVM for KVM-over-IP
Regulatory Compliance BSMI, CE, FCC(Class A)
Dimensions 998mm x 439.5mm x 43.6mm
39.29" x 17.3" x 1.72
Form Factor 1U
Weight NW: 20.5kg
GW: 28.5kg
Power Supply 1+1 Redundant 2200W CRPS 80 PLUS Platinum Power Supply
Rating: 100-127Vac/200-240Vac,14A/12.6A (x2), 47-63Hz
Environment Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C
Non operation humidity: 20% ~ 90% ( Non condensing)
